PHOTINI — Sensing Drone
Introduction
Navigate to detected coordinates and directly collect and measure water samples at the target location.
Main Feature / Specs.
| Type | Hexacopter (In-house Developed) |
| Dimensions | 1,900 × 1,900 × 930 mm |
| Motors · Propellers | X9 · 36″ 19P |
| Battery | 14S 22,000 mAh |
| Camera | 4K 3-Axis Gimbal |
| Water Sampling | Max. depth 30 m · Capacity 4 L |
Role: End-to-end water sampling and quality measurement at detected coordinates
- Weight: 30 kg · Maximum Takeoff Weight: 46 kg
- Flight Performance: 45 min (20 min with 16 kg payload) · Wind Resistance: 14 m/s
- Payload & Measurements: DANA + DAVID · Real-time pH, EC, and turbidity monitoring
